Humminbird HELIX 12 CHIRP GPS Md: 410390-1

Humminbird HELIX 12 CHIRP GPS Md: 410390-1

The SOLIX 12 features a large 12.1" display with LED backlight, CHIRP sonar with up to 8000 Watts PTP power output, GPS Chartplotting with built-in maps, and Ethernet networking capabilities. Includes unit cover and Cross Touch Interface



Features :

- Broadband CHIRP Sonar

- Xtreme Depth

- 360° Imaging

- SwitchFire

- DualBeam Plus Sonar

- Internal GPS

- Upgradeable Software

- Dual Card Slot

- High Definition Display

- Ethernet

- HD Radar

- Ais

- AutoPlot

- Nmea

- I-Plot Link

- AutoChart Live

- Cross Touch

- SmartStrike

- Nmea 0183/2000

- Precision GPS



Specifications :

- Display Size: 12.10" (Diagonal)

- Display Pixel Matrix: 1280H x 800V

- Display Type: Color TFT

- Display Colors Grayscale: 16 Bit

- Sonar Standard: DualBeam PLUS

- Standard Sonar Coverage: 20° and 60° at -10db

- Standard Sonar Frequency: 83/200 kHz

- Sonar Optional: 50kHz, 50/Low Airmar CHIRP and SM3000

- Target Separation: 2.50"

- Power Output RMS: 1000 Watts

- Power Output Peak to Peak: 8000 Watts*

- Depth Capability: 1500' and 3500'

- Temperature: Built In Transducer

- Speed: GPS Speed Included

- Backlight: LED

- Unit Size Gimbal Mount: 13.82" W x 9.55" H x 4.79" D

- Mount A Type: Gimbal Mount

- Unit Size Indash Mount: 13.82" W x 8.21" H x 4.79" D

- Mount B Unit Size 2 :In-Dash

- Mounting Options: Gimbal or Optional In-Dash

- Transducer Standard: XNT 14 20 T

- Transducer Mounting: Transom

- Optional Sonar: 50kHz, 50/Low Airmar CHIRP and SM3000

- Power Input: 10.8-20 VDC

- Power Draw: 2.88 Amps

- GPS Receiver: Included

- GPS Tracking: Included

- GPS Chartplotting: Included

- Waypoints, Routes, Tracks/Points: 10,000, 50, 50/20,000

- Humminbird Mapping: Optional

- Navionics+: Optional

- Navionics Platinum+: Optional

- Platinum Capable: Optional

- C-Map 4D: Not Supported

- 360 Imaging: Optional

- i-Pilot Link: Optional

- HD Radar: Optional

- NMEA 2000: Optional

- 5 Port Expansion Module: Optional

- WeatherSense: Not Supported

- Precision GPS: Included

- Heading Sensor GPS: Optional

- PC Connect: Optional

- External GPS Receiver: Optional

- AS Interlink: Not Supported

- AIS Compatability: Optional

- SwitchFire Sonar: Included

- Screen Snap Shot: Included

- Sonar Recording: Included

- Humminbird PC: Included

- Upgradable Internal Software: Included

- Split Screen Zoom: Included

- Split Screen Bottom Lock: Included

- 3D Chart View: Included

- Large Digits View: Not Supported

- Wide/Narrow Cone Split Screen: Included

- Custom View Selections: Included

- Custom Digital Readout: Included

- View Preset Keys: Not Supported

- Temperature Graph: Included

- Temperature Alarm: Included

- Freeze Frame: Included

- Instant Image Update: Included

- Mark Structure on Sonar: Included

- Selective Fish ID+: Included

- Real Time Sonar: Included

- Triplog: Included

- X-Press Menu System: Included

- Card Reader Available: Yes

- # Card Slots: 2
