The SU-16 is a gas operated, semi-loading rifle chambered in 5.56 mm NATO caliber. It is intended to be the perfect everyman's sport and utility rifle. The rifling is 1 turn in 9 inches, right hand twist. Several unique features make the SU-16 a versatile sporting firearm, including :
* Chrome lined bore and chamber now standard
* An integrated Picatinny rail for mounting different sight systems.
* The forend folds down to form a bipod for increased accuracy.
* The stock can store spare magazines. Two 10 round magazines or one 20/30 round magazine will fit.
* The stock and trigger mechanism can be folded forward for added safety and to facilitate secure storage or carry under extreme conditions.
Technical Specifications
Calibers: .223 Rem 5.56mm
Weight unloaded: 5.0lbs. 2.3kg
Length Open: 37.4" 950.0mm
Length Closed: 26.4" 670.6mm
Barrel length: 18.5" 470.1mm *
Magazine Capacity: 10 rounds 10 rounds
Barrel Diameter: 3/4" to 5/8" 19.1mm to 15.9mm
Twist: 1:9" 1:228.6mm
Bolt Travel: 4.1" 104mm
Trigger Pull: 5lbs to 7lbs 22.2N to 31.1N
Barrel Weight: 26.1oz 738.8g
The SU-16 has a conventional, long-stroke gas-piston operation and utilizes the proven Johnson/Stoner breech locking system. It is compatible with standard AR-15/M-16 magazines. The reciprocating bolt handle and magazine catch are on the right side, while the push bolt safety can be changed to work from either side. Except for barrel and operating components, the SU-16 is made entirely of high impact reinforced polymer.
Caliber Dictionary
The Below Information Has Been Provided From Our Gun Caliber Dictionary And Is Meant For Informational Purposes Only. It Is Not Intended to Describe The Unique Specifications For This Ammunition.
Introduced in 1964, the 223 Remington is the civilian version of the 5.56x45mm NATO cartridge. Although very similar to the 222 Remington it has a slightly longer case and a shorter neck, giving it greater powder capacity and thus higher velocity--which was necessary to meet military penetration requirements at longer range. NOTE: 223 Remington ammunition may be safely fired in any 5.56x45mm chamber, but 5.56x45mm ammunition SHOULD NOT BE USED in a 223 chamber! Standard is a 55-grain bullet at 3240 feet per second, with lighter bullets somewhat faster and heavier bullets a bit slower. The 223 is the most popular 22 centerfire today, and possiby the most popular centerfire cartridge. Ammunition choices are legion, as are choices in firearms. The 223 is an accurate cartridge ideally suited for varmint hunting out to beyond 300 yards, and with heavy-bullet loads designed for the purpose is used effectively by many deer hunters. — Craig Boddington
