Super-X Power Point's unique exposed soft nose jacketed bullet design delivers maximum energy on target. Strategially placed notches around the jacket mouth improve upset and ensure uniform expansion for massive energy release.
Symbol: X2842
Caliber: 284 Winchester
Bullet Weight: 150 grains
Bullet Type: Power Point
Game Selector Guide: Deer, Open or Plains, Medium Game
CPX Guide Number: 3 (large, heavy game)
Velocity (Feet per Second) : - Muzzle: 2860
- 100yds: 2595
- 200yds: 2344
- 300yds: 2108
- 400yds: 1886
- 500yds: 1680
Energy (Foot Pounds) : - Muzzle: 2724
- 100yds: 2243
- 200yds: 1830
- 300yds: 1480
- 400yds: 1185
- 500yds: 940
Trajectory, Short Range : - 50yds: 0.6
- 100yds: 1.00
- 150yds: 0
- 200yds: -2.4
- 250yds: -6.3
- 300yds: -12.1
Trajectory, Long Range:
- 100yds: 2.1
- 150yds: 1.8
- 200yds: 0
- 250yds: -3.4
- 300yds: -8.5
- 400yds: -24.8
- 500yds: -51.0
Caliber Dictionary
The Below Information Has Been Provided From Our Gun Caliber Dictionary And Is Meant For Informational Purposes Only. It Is Not Intended to Describe The Unique Specifications For This Ammunition.
The 284 Winchester was introduced in 1963 in Winchester's Model 88 lever-action rifle. Decades hhead of its time, it is actually one of the first "short, fat" cartridges with a rebated rim and a larger diameter case. The intent was to produce "270 Winchester-like" velocity in a cartridge that can be housed in short actions, and although the 284 Winchester was never popular it comes pretty close: The remaining factory load pushes a 150-grain bullet at 2860 feet per second. Winchester has been the only producer of ammunition, but several bolt-action rifles have been chambered to 284 Winchester. It is actually a good cartridge that doesn't deserve to be as overlooked as it has been. — Craig Boddington
Specifications
Manufacturer: Winchester
Manufacturer No : X2842
SKU : 19255
UPC : 020892200685
Warranty : Warranted against manufacturers defects.
